Metcal HCT2-200 Digital Hot Air Pencil 220V

SKU: METHCT2-200-21

HCT2-200-21

$855.31

EX. GST
$940.84
INC GST
In Stock

Order before 2pm today for same day dispatch of up to units from our Sydney warehouse.

own it from $10 a week with Group 2 Copy Created with Sketch.

DESCRIPTION
Features & Benefits
Contents
Specifications
Resources
Shipping & Delivery

Metcal HCT2-200 Digital Hot Air Pencil 220V

The HCT2-200-21 Hot Air Pencil is a digital handheld convection tool that is ideally suited for light rework applications, which use smaller components and integrated circuits.

As component miniaturization continues (i.e. 01005 components) the ergonomics of a pencil allow a user more freedom to access and rework components on the board without affecting adjacent parts. Larger handheld convection systems commonly reflow and dislodge adjacent components due to a higher minimum airflow.

The HCT2 series of Digital Hot Air Pencils have always included an array of nozzle sizes and precision control. The HCT2-200's improved thermal performance allows the user to target a larger variety of components. Metcal has made working under a microscope easier with the optional bent nozzles. Add the HCT2-200-21 to your workbench and experience improved performance.

HCT2-200-21 was developed for very small surface mount components and package sizes (1206s and smaller) and low board densities. For denser PCBAs or applications with heavy copper planes; boards > 4 layers; or components larger than 5mm, the use of a Metcal preheater (PCT-100 series) may be necessary.

Discover the Metcal HCT2-200 Digital Hot Air Pencil 220V at Mektronics Australia – your trusted source for quality tools and equipment!

  • 200 Watt Ceramic Heater and Dual-Stage Air Pump: Provides the power and performance needed to deliver the right amount of thermal energy.

  • Digital Airflow & Temperature Controls: Two LED displays provide a graphical and numerical representation of the desired airflow and temperature.

  • Fast Response and Performance: A microprocessor controlled, closed-loop feedback system provides fast heating, precise and stable temperature control.

  • Standby Mode: When the handpiece is placed into the workstand, the temperature will drop, prolonging heater life.

  • Replaceable Handpiece: The handpiece has been redesigned to allow removal from the front of the unit.

  • Ergonomic and Light Weight Handpiece: Slim and ergonomic design hand-piece that feels like a pencil, with a rubber grip.

  • Easily Change Heaters, Nozzles, and Handpieces: All can be changed in moments.

  • Nozzles: Six nozzles (1.5 mm – 4.0 mm) are included with the unit, with a nozzle plate holder inside the workstand.

  • Base Unit

  • Handpiece

  • Workstand w/ Nozzle Holder

  • Heater Assembly

  • Pack of 6 Straight Nozzles

  • Nozzle Removal Pad

Input Voltage: 240 VAC, 50 Hz
Rated Power: 200 W
Source Temperature: 100 - 450 °C (212 - 842 °F)
Heating Method: Convection
Airflow: 1.5 - 7 l/min
Noise Level: < 52 dBA at maximum airflow
Surface Resistivity: 105 - 109 Ohm
Display: Temperature & Air Flow
Size W x D x H: 10.6 x 21.3 x 17 cm (4.2" x 8.4" x 6.7")
Weight: 2.63 kg (5.8 lb)
Certification/Marking: CNRTLus, CE, RoHS + WEEE
Ambient Operating Temperature: 10 - 40 °C (50 - 104 °F)
Power Cord Length: 183 cm, 18/3 SJT
Warranty: 1 Year
