JBC MV-A Pneumatic Suction System




Out of Stock: Available to Order

own it from $10 a week with Group 2 Copy Created with Sketch.

Shipping & Delivery

JBC MV-A Pneumatic Suction System

It is required available compressed air at the operator´s bench.

The pneumatic suction module is indispensable for a complete desoldering process.

Discover the JBC MV-A Pneumatic Suction System at Mektronics Australia – your trusted source for quality tools and equipment!

  • By using compressed air and a Venturi valve, the system provides the best results due to its instantaneous vacuum ramp.
  • is equipped with some suction filters easy to change in order to extend the pump´s life.
  • MV is compatibe with CV station and DI control unit which manage the tip temperature while module removes the molten solder.
  • MV works with the comfortable DS360 or DR560 desoldering irons and their corresponding tips.
Net Weight 679 gr (1.50 lb)
Size 145x55x225mm
(5.71 x 2.17 x 8.86 in)
Air pressure 4 - 6 Bar
Vacuum (at 6 Bar) 90% / 680mmHg / 26.8inHg
Flow rate 15 SLPM
Ambient operating temp. 10-40 ºC / 50-104 ºF
ESD Safe
Package weight 982 gr (2.16 lb)
Dimensions 285 x 195 x 115 mm
(11.22 x 7.68 x 4.53 in)
