Image for Illustrative Purposes Only
JBC 230 V - Precision Hot Air Station Without Extractor Desk
SKU: JBC-TESE-2QB
TESE-2QB
DESCRIPTION
Specifications
Product Composition
Shipping & Delivery
JBC 230 V - Precision Hot Air Station Without Extractor Desk
The TESE-Q is aprecision hot air Station capable of reworking small and medium SMDs. Watch video for examples.
Connecting an external thermocouple provides a high-precise close-loop control of the component/PCB during the rework process or can also be used to protect a component or a specific area of the PCB.
As all the JBC Stations, the TESE-Q has a menu with more than 10 parameters to customise the control unit.
Discover the JBC 230 V - Precision Hot Air Station Without Extractor Desk at Mektronics Australia – your trusted source for quality tools and equipment!
-
Selectable temperature: 150 to 450 ºC (300-840 ºF)
-
Air flow: 2 to 17 SLPM
-
Temperature Profiles: Design specific thermal profiles to avoid thermal shock during soldering processes. Up to 25 fully configurable soldering profiles can be stored.
-
Operating Modes: Heating / Profiles / Cooling
-
Vacuum: 30% / 228 mmHg / 9 inHg
-
ESD Safe
-
Nominal power: 300W
-
Operating temp range: 10 to 50 ºC / 50 to 120 ºF
-
Dimensions: 232 x 148 x 160mm / 3.44kg
Connectivity
-
Type K Thermocouple: Can be used both for control and protection purposes
-
USB-B (rear): Software PC
-
USB-A (front): Firmware update, graphics / profiles management
-
Robot: RS-232 remote control
-
Pedal: Optional tool control
-
Equipotential Bonding: Optional connective to EPA
-
Hot Air Control Unit
-
TET Precision Heater Hose Set
-
TES Stand for TET Precision Heater Hose Set
-
TN9209 Straight Nozzle Ø3 for TET
-
TN9208 Straight Nozzle Ø4 for TET
-
TN9080 Straight Nozzle Ø5 for TET
-
PH218 Thermocouple Type K
