Image for Illustrative Purposes Only
Fluke Logo

Fluke T150 Voltage & Continuity Tester With LCD

SKU: FLUT150

T150

$418.00

EX. GST
Regular price $536.80
$459.80
INC GST
Regular price $536.80
Out of Stock: Available to Order

own it from $10 a week with Group 2 Copy Created with Sketch.

DESCRIPTION
Key Features
Additional Features
Selection Guide
Specifications
Shipping & Delivery

Fluke T150 Voltage & Continuity Tester With LCD

Fluke Two-pole Voltage and Continuity Testers give you fast test results the way you need them, with large, easy-to-use buttons, bright backlights, and clear audible and physical indicators designed for any work situation. Resistance measurements up to 1999 Ω. Display hold. Enhanced ergonomic design is easy to use (even with gloves on) and offers quick, secure probe docking.

Two-pole voltage and continuity testers measure voltage, but just as important is when a two-pole tester tells you that there is NOT voltage present before working on any circuit. For you to rely on your two-pole tester, it has to be the most rugged and reliable tester you can find. That's what Fluke's redesigned two-pole testers give you.

Fluke knows the cable assembly is often where failures occur. The cable on any Two-Pole voltage and continuity tester is its weakest point- it is repeatedly bent, twisted, wrapped and put under constant strain. If the cable were to break, it could place you at an increased safety risk. Industry standards call for the cable to be tested to withstand a forty-five-degree bend, and still work after 5000 bend cycles. Fluke puts our testers through three times what the standard demands, flexing the cable over 150 degrees in each direction. This is why we can offer you our strongest voltage and continuity testers warranty ever.

Discover the Fluke T150 Voltage & Continuity Tester With LCD at Mektronics Australia – your trusted source for quality tools and equipment!

Fluke's two-pole voltage and continuity testers are built to work the way you work. They give you the best combination of safety, ease-of-use and fast answers available anywhere.

  • Designed according to IEC EN 61243-3:2014 to verify the absence of voltage "“ even with discharged batteries.

  • CAT IV 600 V, CAT III 690 V safety rating

  • With 4 ways to indicate the presence of voltage "“ LED indicator, LCD display, audible tone or tactile feedback, always know if hazardous voltage is present (digital display on T130, T150, vibration indicator on T110, T130, T150)

  • Dual insulated cable tested to 3x the required bend angle provides increased reliability and durability.

  • Switchable load: avoid display of ghost voltages allowing you to draw more current from the circuit under test and avoid trip residual-current devices (RCDs)

  • Backlit graduated scale and backlit indicators

  • Built in electric torch for use in dark areas. (T110, T130, T150)

  • Resistance testing to 1999 ohms. (T150)

  • Audio on/off for testing in quiet areas. (T110, T130, T150)

  • Improved probe docking for secure storage.

  • Phase rotation indicator for 3-phase systems. (T110, T130, T150)

  • Display hold freezes reading on display until your can view it comfortably. (T130, T150)

  • Single-pole phase test offers fast identification of live conductors.

  • Push-on probe tips, probe tip protector and storage accessory.

  • Tip protector serves as an extra hand when opening UK electrical safety outlets.

  • Low battery indicator.

Features

T150

T130

T110

T90

Backlit LED indicator

Backlit LCD digital display

LCD

LCD

Continuity test"”visual results

Continuity test"”audible results

with on/off

with on/off

with on/off

Vibratory indicator under load

Display hold

Voltage test

Indication of polarity

Resistance measurement

Switchable load

Single pole test for phase detection

Rotary field indicator

Probe tip protection

Voltage detection with discharged batteries

Electrical torch function

Wear indicator test lead wire


Specifications

T90

T110

T130

T150

Voltage AC/DC

12V - 690V

12V - 690V

6V - 690V

6V - 690V

Continuity

0 - 400 kΩ

0 - 400 kΩ

0 - 400 kΩ

0 - 400 kΩ

Frequency

0 / 40 - 400 Hz

0 / 40 - 400 Hz

0 / 40 - 400 Hz

0 / 40 - 400 Hz

Phase rotation

-

100 V - 690 V

100 V - 690 V

100 V - 690 V

Resistance measurement

-

-

-

Up to 1999 Ω

Response Time (LED indicator)

< 0.5 s

< 0.5 s

< 0.5 s

< 0.5 s

200 kΩ input impedance

Current draw 3,5 mA @ 690 V

Current draw 1,15 mA @ 230 V

Current draw 3,5 mA @ 690 V

Current draw 1,15 mA @ 230 V

Current draw 3,5 mA @ 690 V

Current draw 1,15 mA @ 230 V

Current draw 3,5 mA @ 690 V

Current draw 1,15 mA @ 230 V

7k Ω input impedance (with load buttons pressed)

-

Current draw 30 mA @ 230 V

Current draw 30 mA @ 230 V

Current draw 30 mA @ 230 V

Safety rating

CAT II 690V

CAT III 600V

CAT III 690V

CAT IV 600V

CAT III 690V

CAT IV 600V

CAT III 690V

CAT IV 600V

IP rating

IP54

IP64

IP64

IP64

Power requirement

2-AAA batteries

2-AAA batteries

2-AAA batteries

2-AAA batteries

Net weight

280 g (9.9 oz)

280 g (9.9 oz)

280 g (9.9 oz)

180 g (6.4 oz)

Size (LxWxH)

26 cm x 7 cm x 3.8 cm

26 cm x 7 cm x 3.8 cm

26 cm x 7 cm x 3.8 cm

23 cm x 6.5 cm x 3.8 cm

Warranty

2 years

2 years

2 years

2 years

Country of origin

Great Britain

Great Britain

Great Britain

Great Britain
