Fluke ACD-10 PLUS 600A Clamp Multimeter

• Thin jaws, only 10mm (0.4) thick
• Continuity buzzer
• Frequency measurement
• In rush current
• Hold & maximum reading functions
• Accommodates conductors up to 26mm (1.02) in diameter
• Auto ranging
• Auto power off
• Rubber over-moulded case
• Overload protected

• Industrial, Maintenance & Repair, Test & Measurement, Portable Devices

Display: 3-3/4 digits 4000 counts LCD display
Update Rate 3 per second nominal
Polarity: Automatic
Operating Temperature: °C to 40 °C; < 80% RH for temperature up to 31 °C decreasing linearly to 50% RH at 40 °C
Altitude: Operating below 2000m; Indoor use
Storage Temperature: -20 °C to 60 °C, < 80% RH (with battery removed)
Temperature Coefficient: nominal 0.15 x (specified accuracy)/°C @(0 °C ~ 18 °C or 28 °C ~ 40 °C)
Low Battery: Below approx. 2.4V
Power Supply: 3V coin battery IEC-CR2032
Power Consumption: 2.8 mA typical except that 3.3 mA typical for ACA function
APO Timing: Idle for 30 minutes
APO Consumption: 5 μA typical
Jaw Opening & Conductor Diameter: max 26 mm
Special Features: 30ms Max Hold; Data Hold; Relative Zero mode

Data Sheet
