Bernstein Feeler Gauge 21 Blades 20mm

SKU: BER7-515

7-515

$27.72

EX. GST
$30.49
INC GST
In Stock

Order before 2pm today for same day dispatch of up to units from our Sydney warehouse.

own it from $10 a week with Group 2 Copy Created with Sketch.

DESCRIPTION
Features
Contents
Shipping & Delivery

Bernstein Feeler Gauge 21 Blades 20mm

With the feeler gauges gap measurements can be measured, it consists of a set (compartments) of hardened metal strips with different strength. Testing and measuring equipment are the most important tools and belong on every workbench or in every tool case. Sensor gauges are used where measuring with calipers or gauges is not possible or cumbersome, often when adjusting electrical contact switches.

T2 TOLERANCES table, see below. You should pay attention to the following errors during measurement in order to obtain a correct measurement result. Keep the feeler gauge as well as the part to be measured calm and straight, do not tilt it. At best you have a constant reference temperature of 20 degrees Celsius, strong temperature fluctuations change the measurement results. Please check your feeler gauge regularly for damage, quirks, indentations and remove soiling immediately.

Discover the Bernstein Feeler Gauge 21 Blades 20mm at Mektronics Australia – your trusted source for quality tools and equipment!

  • measuring range of 0.05 to 2.0 mm

  • 0.05 - 0.1 - 0.2 - 0.3 - 0.4 - 0.5 - 0.6 - 0.7 - 0.8 - 0.9 - 1.0 - 1.1 - 1. 2 - 1.3 - 1.4 - 1.5 - 1.6 - 1.7 - 1.8 - 1.9 - 2.0

  • figures in mm and inches

  • tolerance according to T2 (see content)

  • INOX stainless quality steel

  • conical leaf shape

  • cover sheet nickel plated with locking screw

  • length 100 mm

  • weight 190 g

T2 TOLERANCES

  • Nominal thickness 0.05 +/- 0.004 mm

  • Nominal thickness 0.10 +/- 0.005 mm

  • Nominal thickness 0.20 +/- 0.008 mm

  • Nominal thickness 0.30 +/- 0.009 mm

  • Nominal thickness 0.40 +/- 0.012 mm

  • Nominal thickness 0.50 +/- 0.014 mm

  • Nominal thickness 0.60 +/- 0.014 mm

  • Nominal thickness 0.70 +/- 0.017 mm

  • Nominal thickness 0.80 +/- 0.019 mm

  • Nominal thickness 0.90 +/- 0.022 mm

  • Nominal thickness 1.00 +/- 0.024 mm

  • Nominal thickness 1.10 +/- 0.024 mm

  • Nominal thickness 1.20 +/- 0.024 mm

  • Nominal thickness 1.30 +/- 0.028 mm

  • Nominal thickness 1.40 +/- 0.028 mm

  • Nominal thickness 1.50 +/- 0.028 mm

  • Nominal thickness 1.60 +/- 0.033 mm

  • Nominal thickness 1.70 +/- 0.033 mm

  • Nominal thickness 1.80 +/- 0.033 mm

  • Nominal thickness 1.90 +/- 0.035 mm

  • Nominal thickness 2.00 +/- 0.035 mm
