BenchVent Air Filtration Cabinet A200H
The BenchVent BV260S recirculating spray booth is bigger than the BV300S and with its 2 external rotor axial fans and it’s as powerful as the more expensive BV200S. It can take up to B3 size artwork, which is between an A3 and an A2 size 3.
The BV260S is portable and an ideal air filtration solution for hobby work shops, design and technology classrooms, as well as airbrushing demos in shops or during exhibitions and shows.
This is a recirculating unit and doesn’t require an external vent. Instead, it is fitted with carbon impregnated fibre filter which makes it suitable for use with solvent fumes.
The BV260S is not recommended for continued use, such as in production applications, especially in extremely confined areas where harmful solvent vapours and fumes may accumulate.
Comes with lifetime warranty.
Place the unit on a desk, bench or trolley, attach the shield, plug in and switch on.
The BenchVent BV260S re-circulating spray booth can be used in two positions:
-
Reclining (on back stand) – ideal for spray mounting artwork or applying lacquers or fixatives.
-
Upright: For airbrushing models, light grinding particles, sanding and general solvent dilution.
This unit is designed predominantly for studio, D&T classrooms, workshop cleanliness and for immediate operator protection against concentrations of airborne contaminants. They are not recommended for continuous usage such as production applications, particularly in confined and/or badly ventilated areas.
Discover the BenchVent Air Filtration Cabinet A200H at Mektronics Australia – your trusted source for quality tools and equipment!
-
Body: Black powder coated steel case with white back stand and black carry handle
-
Filters: Particulate + Carbon Impregnated Fibre Filter
-
Motor: 2x external rotor motor axial fans, brushless, UL, VDE and CSA approved
-
Others: Sealed electrical wiring and switch, downstream of filters
Includes filtration of solvent fumes and mist from aerosol adhesives, aerosol lacquers, fixatives, resins, solder fumes, dusts and airbrush spray paints.
Recommended Applications
-
Craft
-
Hobby
-
Scale model painting
-
Airbrush painting
-
Light grinding particles and dusts
-
Cleaning solvents
| Dimensions |
615x490x495mm (WxDxH) |
|---|---|
| Description |
Steel construction finished in black –– plastic replaceable spray/fume shield – back stand / carry handle – particulate filter – carbon impregnated fibre filter – axial fan, external rotor motor type brushless, UL, VDE and CSA approved – sealed electrical wiring and switch, downstream of filters. |
| Air Volume at Free Air |
610 m3/hr |
| Ave. Air Velocity at filter face |
0.60 m/sec |
| Ave. Air Velocity at Hood Face |
0.35 m/sec |
| Fan Motor Spec |
230 V 50Hz 90W, 115V 60Hz 84W |
| Noise Level dB(A) |
61 db(A) |
